| PartNumber | HSD101PUW1-E00 |
| Brand | HannStar |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1920×1200 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 225PPI |
| Active Area | 216.576(H)×135.36(V) mm |
| Luminance | - |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | 16.7M 50% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Interface Type | MIPI (4 data lanes) , 39 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | HSD101PUW1-E00 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Light Source | WLED , 10K hours |
| Designed For | Pad & Tablet |
| Touch Panel | Without |
