| PartNumber | HSD104KXN1-A20 |
| Brand | HannStar |
| Size | 10.4 |
| Application | Automotive Display |
| Resolution | 1024×768 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 900:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | |
| Manufacturer | HannStar |
| Model Name | HSD104KXN1-A20 |
| Screen Size | 10.4 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 123PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 211.2 × 158.4 (H×V) |
| Outline(mm) | - |
| Luminance | - |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | - |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Color Depth | 262K/16.2M |
| Mass | - |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
