| PartNumber | HSD121KXN1-A10-0299 |
| Brand | HannStar |
| Size | 12.1 |
| Application | Automotive Display |
| Resolution | 1024×768 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 900:1 |
| Colors | 262K/16.7M |
| Backlight | No B/L , No Driver |
| Interface | LVDS |
| Manufacturer | HannStar |
| Model Name | HSD121KXN1-A10-0299 |
| Screen Size | 12.1 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 105PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 245.76 × 184.32 (H×V) |
| Outline(mm) | 256.18 × 196.9 × 1.27 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | - |
| Color Depth | 262K/16.7M 70% NTSC |
| Mass | 160/180g (Typ./Max.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
