| PartNumber | HSD121KXN1-B00 |
| Brand | HannStar |
| Size | 12.1 |
| Application | Automotive Display |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 12.1 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 105PPI |
| Active Area | 245.76(H)×184.32(V) mm |
| Luminance | 600 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Model | HSD121KXN1-B00 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Light Source | WLED , 30K hours , With LED Driver |
| Designed For | Automotive Display |
| Touch Panel | Without |
