| PartNumber | HSD123KPW1-A30 |
| Brand | HannStar |
| Size | 12.3 |
| Application | Automotive Display |
| Resolution | 1920(RGB)×720, 167PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 850 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 11S4P |
| Interface | |
| Panel Brand | HannStar |
| Panel Size | 12.3" |
| Display Area | 292.032(W)×109.512(H) mm |
| Outline Size | 308.1(W)×130(H) ×15.6(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 71% NTSC |
| Frequency | 60Hz |
| Weight | 520g (Typ.) |
| Panel Model | HSD123KPW1-A30 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 294.8(W)×112.1(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Response Time | 17/18 (Typ.)(Tr/Td) |
| Lamp Type | 11S4P WLED , 30K hours , Without Driver |
| Touch Screen | Without |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
