| PartNumber | HSD150GXN1-A00-C00 |
| Brand | HannStar |
| Size | 15.0 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 15.0 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| Active Area | 304.128(H)×228.096(V) mm |
| Bezel Area | 307.4(H)×231.3(V) mm |
| Luminance | 250 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Support Color | 262K/16.2M 60% NTSC |
| Weight | 1.20Kgs (Max.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| Model | HSD150GXN1-A00-C00 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 326.5(H)×253.5(V) ×12.7(D) mm |
| Treatment | - |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Response Time | 12 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 30K hours , With LED Driver |
| Designed For | Industrial |
| Touch Panel | Embeded Touch |
