| PartNumber | HSD156JUW2-A12 |
| Brand | HannStar |
| Size | 15.6 |
| Application | Outdoor High Brightness Automotive Display |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 850 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 4 |
| Interface | |
| Panel Brand | HannStar |
| Panel Size | 15.6" |
| Display Area | 344.16(W)×193.59(H) mm |
| Outline Size | 363.7(W)×215.7(H) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 70% |
| Frequency | 60Hz |
| Weight | TBD |
| Panel Model | HSD156JUW2-A12 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Response Time | 15/15 (Max.)(Tr+Td) |
| Lamp Type | 4 strings WLED , 30K hours , Without Driver |
| Touch Screen | Without |
