| PartNumber | JJ068IA-07B |
| Brand | Innolux |
| Size | 6.8 |
| Application | Outdoor High Brightn |
| Resolution | 1280×720 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 6S3P WLED , 20K hours , No Driver |
| Interface | |
| Manufacturer | Innolux |
| Model Name | JJ068IA-07B |
| Screen Size | 6.8 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×720 (WXGA) 217PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 152.064 × 79.603 (H×V) |
| Outline(mm) | 167 × 93 × 9.75 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare |
| Luminance | 750 cd/m² (Typ.) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 15/10 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 16.7M 70% NTSC |
| Mass | 185g (Typ.) |
| Used for | Outdoor High Brightness Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| ND068-101A1 | 6.8 | 1280×480 |
