| PartNumber | JJ070IA-18L |
| Brand | Innolux |
| Size | 7.0 |
| Application | Automotive Display |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 7S2P WLED , 20K hours , No Driver |
| Interface | LVDS |
| Manufacturer | Innolux |
| Screen Size | 7.0 inch |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Bezel Area(mm) | 155.4 × 94.44 (H×V) |
| Luminance | 750 cd/m² (Typ.) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 70% NTSC |
| Mass | 195±9g |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 8-bit) , 50 pins FPC |
| Voltage Supply | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Model Name | JJ070IA-18L |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 162.8 × 104.84 (H×V×D) |
| Treatment | Antiglare |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 15/10 (Typ.)(Tr/Td) ms |
| Work Mode | IPS, Normally Black, Transmissive |
| Used for | Automotive Display |
| Touchscreen | Without |
