| PartNumber | JR645R3HA1L |
| Brand | SDP |
| Size | 65 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | |
| Manufacturer | SDP |
| Model Name | JR645R3HA1L |
| Screen Size | 65 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 68PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1428.48 × 803.52 (H×V) |
| Outline(mm) | 1438.48 × 815.02 × 1.33 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare (Haze 5%), Hard coating (2H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 4000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | UV2A, Normally Black, Transmissive |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | 5.1% (Typ.)(with Polarizer) |
| Color Depth | 1.07B 71% NTSC |
| Mass | 3.45±0.17Kgs |
| Used for | TV Sets |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
