| PartNumber | JR645R3HA3L |
| Brand | SDP |
| Size | 65 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 68PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | V-by-One |
| Panel Brand | SDP |
| Panel Model | JR645R3HA3L |
| Panel Size | 65" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1428.48(W)×803.52(H) mm |
| Bezel Opening | - |
| Outline Size | 1440.28(W)×815.92(H) ×1.33(D) mm |
| Surface | Antiglare (Haze 5%), Hard coating (2H) |
| Contrast Ratio | 4000:1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Display Mode | UV2A, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 5.1% (Typ.)(with Polarizer) |
| Display Colors | 1.07B 71% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 12 source chips |
| Panel Weight | 3.45±0.17Kgs |
| Signal Interface | V-by-One 8 lane , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| LC650EQD-FGF4 | LG Display | 65 | 3840×2160 |
| LC650EQF-FHM1 | LG Display | 65 | 3840×2160 |
| LC650EQF-FHM2 | LG Display | 65 | 3840×2160 |
| LC650EQF-FJM1 | LG Display | 65 | 3840×2160 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
| T645HW04 V0 CELL | AUO | 65 | 1920×1080 |
| T650HVJ02.0 | AUO | 65 | 1920×1080 |
| T650HVN05.4 | AUO | 65 | 1920×1080 |
| T650QVD01.0 CELL | AUO | 65 | 3840×2160 |
