| PartNumber | KB860DU15-L01 |
| Brand | BEST |
| Size | 86 |
| Application | Digital Signage Outd |
| Resolution | 3840×2160 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1200:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | V-by-One |
| Diagonal Size | 86 inch |
| Pixel Format | 3840(RGB)×2160 [UHD] 51PPI |
| Active Area | 1895.04(H)×1065.96(V) mm |
| Bezel Area | - |
| Luminance | 1500 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Support Color | 1.07B 68% NTSC |
| Weight | 55.0Kgs (Typ.) |
| Frame Rate | 60Hz |
| Interface Type | V-by-One 8 lane , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | KB860DU15-L01 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 1930(H)×1105.5(V) mm |
| Treatment | Antiglare (Haze 1%), Hard coating (2H) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Response Time | 8 (Typ.)(G to G) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Light Source | WLED , 30K hours , With LED Driver |
| Designed For | Digital Signage Outdoor High Brightness |
| Touch Panel | Without |
