| PartNumber | KHS038AA1AG-G83 |
| Brand | Kyocera |
| Size | 3.8 |
| Application | Industrial |
| Resolution | 240×320 |
| Composition | LCM , CSTN-LCD |
| Brightness | |
| CR | 15:1 |
| Colors | Color |
| Backlight | 1 pcs CCFL , No Driver |
| Interface | Parallel |
| Manufacturer | Kyocera |
| Screen Size | 3.8 inch |
| Pixel Number | 240(RGB)×320 (QVGA) 105PPI |
| Active Area(mm) | 57.58 × 76.78 (H×V) |
| Luminance | 16 cd/m² (Typ.) |
| Viewing Angle | 50/45/20/30 (Typ.)(CR≥2) |
| Good View at | - |
| Color Depth | Color |
| Mass | - |
| Refresh Rate | 75Hz |
| Signal Type | Parallel Data (1ch, 8-bit) FPC |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | KHS038AA1AG-G83 |
| Screen Type | LCM , CSTN-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | - |
| Contrast Ratio | 15 : 1 (Typ.) (TM) |
| Response | 250/150 (Typ.)(Tr/Td) ms |
| Work Mode | STN, Normally Black, Transflective |
| Used for | Industrial |
| Touchscreen | - |
