| PartNumber | LA070WV2-TD01 |
| Brand | LG Display |
| Size | 7.0 |
| Application | Automotive Display |
| Resolution | 800(RGB)×480, WVGA, 133PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 550 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 9S2P |
| Interface | Parallel |
| Panel Brand | LG Display |
| Panel Model | LA070WV2-TD01 |
| Panel Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | 154.45(W)×93.24(H) mm |
| Outline Size | 169(W)×103.45(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 6/9 (Typ.)(Tr/Td) |
| Display Colors | 262K 64% NTSC |
| Lamp Type | 9S2P WLED , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 165/175g (Typ./Max.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| Input Voltage | 3.3/10.0/18.5/-8.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
