| PartNumber | LA070WV7-SL02 |
| Brand | LG Display |
| Size | 7.0 |
| Application | Outdoor High Brightn |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1100:1 |
| Colors | 16.7M |
| Backlight | 6S3P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | LG Display |
| Model Name | LA070WV7-SL02 |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Outline(mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| Bezel Area(mm) | 158.4 × 94.2 (H×V) |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1100 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 16/14 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M 65% NTSC |
| Mass | 162/167g (Typ./Max.) |
| Used for | Outdoor High Brightness Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , FPC 50 pins |
| Voltage Supply | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
