| PartNumber | LA102WH2-SL01 |
| Brand | LG Display |
| Size | 10.2 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 10S4P WLED , 10K hours , No Driver |
| Interface | LVDS |
| Manufacturer | LG Display |
| Model Name | LA102WH2-SL01 |
| Screen Size | 10.2 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×720 (WXGA) 143PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 225.792 × 127.008 (H×V) |
| Outline(mm) | 238.62 × 141.5 (H×V×D) |
| Bezel Area(mm) | 225.75 × 126.874 (H×V) |
| Treatment | Hard coating (3H) |
| Luminance | 725 cd/m² (Min.) |
| Contrast Ratio | 800 : 1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Response | 30 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M |
| Mass | 303/313g (Typ./Max.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , FPC 64 pins |
| Voltage Supply | 1.8/3.3/12.5/18.5/-7.5V (Typ.)(DVDD2/DVDD1/AVDD/VHG/VHL) |
| Max. Ratings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.16G (31.0 m/s²) |
