| PartNumber | LA123WF4-SR09 |
| Brand | LG Display |
| Size | 12.3 |
| Application | Automotive Display |
| Resolution | 1920(RGB)×720, 167PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 600 cd/m² (Min.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 8S6P |
| Interface | RSDS |
| Panel Brand | LG Display |
| Panel Model | LA123WF4-SR09 |
| Panel Size | 12.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 292.032(W)×109.512(H) mm |
| Bezel Opening | 296.03(W)×113.5(H) mm |
| Outline Size | 310(W)×128(H) ×10.75(D) mm |
| Surface | Antiglare, Antireflection |
| Contrast Ratio | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Max.)(G to G); 30 (Typ.)(MPRT) |
| Display Colors | 16.7M 77% NTSC |
| Lamp Type | 8S6P WLED , 10K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | RSDS (2 Channel) , 110 pins FPC |
| Input Voltage | 3.3/13.0V (Typ.)(VCC/VDD) |
| Environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
