| PartNumber | LC430EQL-SLA1 |
| Brand | LG Display |
| Size | 43 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | CELL , a-Si TFT-LC |
| Brightness | |
| CR | 1400:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | V-by-One |
| Manufacturer | LG Display |
| Model Name | LC430EQL-SLA1 |
| Screen Size | 43 inch |
| Screen Type | CELL , a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 103PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 941.184 × 529.416 (H×V) |
| Outline(mm) | 953 × 543 × 1.2 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1400 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Response | 5 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Glass Thickness | - |
| Transmissivity | 4.24% (Typ.)(with Polarizer) |
| Color Depth | 1.07B |
| Mass | 1.56/1.65Kgs (Typ./Max.) |
| Used for | TV Sets |
| Refresh Rate | 120Hz |
| Touchscreen | Without |
| Driver IC list | Built-in COF 12 source chips |
| Signal Type | V-by-One 16 lane , 97 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
