| PartNumber | LC470EUG-PEF2 |
| Brand | LG Display |
| Size | 47 |
| Application | TV Sets |
| Resolution | 1920(RGB)×1080, FHD, 46PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 360 cd/m² (Typ.) |
| CR | 1400:1 |
| Colors | 1.06B |
| Backlight | WLED |
| Interface | EPI |
| Panel Brand | LG Display |
| Panel Model | LC470EUG-PEF2 |
| Panel Size | 47" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1039.68(W)×584.82(H) mm |
| Bezel Opening | - |
| Outline Size | 1059.5(W)×616.2(H) mm |
| Surface | Antiglare (Haze 1%), Hard coating (2H) |
| Contrast Ratio | 1400:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8/10 (Typ.)(Tr/Td) |
| Display Colors | 1.06B 68% NTSC |
| Lamp Type | WLED , 50K hours , Without Driver |
| Frequency | 120Hz |
| Touch Screen | Without |
| Panel Weight | 10.5/11.0Kgs (Typ./Max.) |
| Signal Interface | EPI , 100 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC470EUE-SEM2 | LG Display | 47 | 1920×1080 |
| LC470EUF-FEP1 | LG Display | 47 | 1920×1080 |
| LC470EUF-PEF1 | LG Display | 47 | 1920×1080 |
| LC470EUF-SDF1 | LG Display | 47 | 1920×1080 |
| LC470EUF-SDF2 | LG Display | 47 | 1920×1080 |
| LC470EUH-LFF1 | LG Display | 47 | 1920×1080 |
| LC470EUH-PFP1 | LG Display | 47 | 1920×1080 |
| LC470EUN-FEF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SDF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SFM1 | LG Display | 47 | 1920×1080 |
