| PartNumber | LC470WUN-SDA1 |
| Brand | LG Display |
| Size | 47 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | |
| CR | 1450:1 |
| Colors | 16.7M/1.06B |
| Backlight | |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LC470WUN-SDA1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 47 inch |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Active Area | 1039.68×584.82 mm |
| Surface | |
| Contrast Ratio | 1450:1 (Typ.) |
| Display Colors | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| Response Time | 5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | Embedded (Inverter) |
| Signal Interface | LVDS |
| Input Voltage | 12.0V (Typ.) |
