| PartNumber | LC490DUE-FJM1 |
| Brand | LG Display |
| Size | 49 |
| Application | TV Sets |
| Resolution | 1920(RGB)×1080, FHD, 45PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Min.) |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Size | 49" |
| Display Area | 1073.8(W)×604(H) mm |
| Outline Size | 1106.8(W)×640.6(H) mm |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 68% NTSC |
| Frequency | 60Hz |
| Panel Weight | - |
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Input Voltage | 12.7V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | LC490DUE-FJM1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 1078.3(W)×608.5(H) mm |
| Surface | - |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 9 (Typ.)(G to G) |
| Lamp Type | WLED , 50K hours , Without Driver |
| Touch Screen | Without |
