| PartNumber | LC550EQF-YJF1 |
| Brand | LG Display |
| Size | 55 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 80PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1400:1 |
| Colors | 16.7M/1.06B |
| Backlight | WLED |
| Interface | V-by-One |
| Panel Brand | LG Display |
| Panel Model | LC550EQF-YJF1 |
| Panel Size | 55" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1209.6(W)×680.4(H) mm |
| Bezel Opening | - |
| Outline Size | 1232.2(W)×708.6(H) ×50.1(D) mm |
| Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Contrast Ratio | 1400:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| Display Colors | 16.7M/1.06B 87% NTSC |
| Lamp Type | WLED , 30K hours , Without Driver |
| Frequency | 120Hz |
| Touch Screen | Without |
| Panel Weight | 12.5/13.2Kgs (Typ.) |
| Signal Interface | V-by-One 16 lane , 97 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
