LC550EQN-PGF1

LC550EQN-PGF1
LC550EQN-PGF1
LC550EQN-PGF1
LC550EQN-PGF1 thumb LC550EQN-PGF1 thumb LC550EQN-PGF1 thumb
Brand
LG Display
Size
55
Application
LCTV
Resolution
3840×2160
Composition
LCM
Brightness
400
CR
1200:1
Colors
16.7M/1.06B
Backlight
WLED
Interface
V-by-One
In Stock
12295
Specifications
PartNumber LC550EQN-PGF1
BrandLG Display
Size55
ApplicationLCTV
Resolution3840(RGB)×2160 , UHD
CompositionLCM
Brightness400 cd/m² (Typ.)
CR1200:1
Colors16.7M/1.06B
BacklightWLED
InterfaceV-by-One
Panel BrandLG Display
Panel ModelLC550EQN-PGF1
Panel Type a-Si TFT-LCD , LCM
Panel Size55 inch
Display ModeIPS, Normally Black, Transmissive
Active Area1209.6×680.4 mm
Outline1226×702.1×26 mm
SurfaceAntiglare (Haze 1%), Hard coating (2H)
Contrast Ratio1200:1 (Typ.)
Display Colors16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
Response Time6 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceV-by-One 8 lane, 51 pins
Input Voltage12.0V (Typ.)
