| PartNumber | LC650EQC-SPA1 |
| Brand | LG Display |
| Size | 65 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 68PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 1300:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | EPI |
| Panel Brand | LG Display |
| Panel Model | LC650EQC-SPA1 |
| Panel Size | 65" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1428.48(W)×803.52(H) mm |
| Bezel Opening | - |
| Outline Size | 1440.3(W)×817.9(H) ×1.2(D) mm |
| Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Contrast Ratio | 1300:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8/10 (Typ.)(Tr/Td) |
| Glass Depth | - |
| Transmissivity | 5.51% (Typ.) |
| Display Colors | 1.07B 73% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 12 source chips |
| Panel Weight | 3.20/3.36Kgs (Typ./Max.) |
| Signal Interface | EPI , 120 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
