| PartNumber | LC650EQF-DKM1 |
| Brand | LG Display |
| Size | 65 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1400:1 |
| Colors | 16.7M/1.07B |
| Backlight | WLED , 30K hours , No Driver |
| Interface | V-by-One |
| Manufacturer | LG Display |
| Screen Size | 65 inch |
| Pixel Number | 3840(RGB)×2160 (UHD) 68PPI |
| Active Area(mm) | 1428.48 × 803.52 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 400 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M/1.07B 84% NTSC |
| Mass | 20.8/21.9Kgs (Typ./Max.) |
| Refresh Rate | 120Hz |
| Signal Type | V-by-One 16 lane , 92 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | LC650EQF-DKM1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 1452.1 × 827.83 (H×V×D) |
| Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Contrast Ratio | 1400 : 1 (Typ.) (TM) |
| Response | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) ms |
| Work Mode | IPS, Normally Black, Transmissive |
| Used for | TV Sets |
| Touchscreen | Without |
