| PartNumber | LD290EJN-FPN1 |
| Brand | LG Display |
| Size | 28.6 |
| Application | Digital Signage Stre |
| Resolution | 1920×540 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 4 strings WLED , 50K hours , No Driver |
| Interface | LVDS |
| Manufacturer | LG Display |
| Screen Size | 28.6 inch (Native bar) |
| Pixel Number | 1920(RGB)×540 69PPI |
| Active Area(mm) | 698.4 × 196.425 (H×V) |
| Bezel Area(mm) | 700.4 × 198.44 (H×V) |
| Luminance | 500 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 72% NTSC |
| Mass | 1.80/2.00Kgs (Typ./Max.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | LD290EJN-FPN1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 712.8 × 213.74 (H×V×D) |
| Treatment | Antiglare, Hard coating (4H) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 6 (Typ.)(G to G) ms |
| Work Mode | IPS, Normally Black, Transmissive |
| Used for | Digital Signage Stretched Bar LCD |
| Touchscreen | In-Cell Touch |
