| PartNumber | LD860DBN-UJA2 |
| Brand | LG Display |
| Size | 86 |
| Application | Digital Signage Outd |
| Resolution | 3840×600 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1100:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | V-by-One |
| Model | LD860DBN-UJA2 |
| Diagonal Size | 86 inch (Native bar) |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 3840(RGB)×600 45PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 2148.48(H)×335.7(V) mm |
| Outline Dim. | 2158.3(H)×348.5(V) ×82.2(D) mm |
| Bezel Area | 2149.5(H)×336.7(V) mm |
| Treatment | Antiglare (Haze 10%), Hard coating (3H) |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 1100:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 1.07B 98% sRGB |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 15.04Kgs (Typ.) |
| Designed For | Digital Signage Outdoor High Brightness Stretched Bar LCD |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | V-by-One 8 lane , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
