| PartNumber | LH450WX1-SD01 |
| Brand | LG Display |
| Size | 4.5 |
| Application | MPH |
| Resolution | 720(RGB)×1280 , WXGA |
| Composition | LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | LG Display |
| Panel Model | LH450WX1-SD01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 4.5 inch |
| Display Mode | AH3-IPS, Normally Black, Transmissive |
| Active Area | 55.512×98.688 mm |
| Outline | 59.61×108.47 mm |
| Surface | Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193170% |
| Response Time | 17/18 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 9S1PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 30 pins |
| Input Voltage | 1.8/3.0/3.0V (Typ.)(IOVCC/VCI/VCC) |
