| PartNumber | LH570QH6-SD01 |
| Brand | LG Display |
| Size | 5.7 |
| Application | Mobile Phone |
| Resolution | 1440×2880 |
| Composition | Assembly , a-Si TF |
| Brightness | |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | 4S3P WLED , No Driver |
| Interface | MIPI |
| Manufacturer | LG Display |
| Screen Size | 5.7 inch |
| Pixel Number | 1440(RGB)×2880 564PPI |
| Active Area(mm) | 64.8 × 129.6 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 500 cd/m² (Typ.) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 85% NTSC |
| Mass | 26.6±2.7g |
| Refresh Rate | 60Hz |
| Signal Type | MIPI (4 data lanes) , 54 pins Connector |
| Voltage Supply | 1.8/3.3/5.5/-5.5V (Typ.)(VDDI/VPNL/DDVDL/DDVDH) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | LH570QH6-SD01 |
| Screen Type | Assembly , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 68.72 × 145.7 (H×V×D) |
| Treatment | Hard coating |
| Contrast Ratio | 1500 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | - |
| Used for | Mobile Phone |
| Touchscreen | PCAP |
