| PartNumber | LK558Z3LA1P |
| Brand | Sharp |
| Size | 55.8 |
| Application | Digital Signage |
| Resolution | 2560×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1800:1 |
| Colors | 1.07B |
| Backlight | 20 pcs CCFL , 60K hours , With Inverter |
| Interface | LVDS |
| Manufacturer | Sharp |
| Model Name | LK558Z3LA1P |
| Screen Size | 55.8 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 2560(RGB)×1080 49PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1305.6 × 550.8 (H×V) |
| Outline(mm) | 1372 × 610 × 56.2 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 1800 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 4 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ASV, Normally Black, Transmissive |
| Color Depth | 1.07B 74% NTSC |
| Mass | 16.9±1.0Kgs |
| Used for | Digital Signage |
| Refresh Rate | 120Hz |
| Touchscreen | Without |
| Signal Type | LVDS (4 ch, 10-bit) , 92 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
