| PartNumber | LK645D3LZ2U |
| Brand | SHARP |
| Size | 65 |
| Application | PID |
| Resolution | 1080×1920(RGB) , FHD |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 2000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | SHARP |
| Panel Model | LK645D3LZ2U |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 65 inch |
| Display Mode | ASV, Normally Black, Transmissive |
| Active Area | 803.52×1428.48 mm |
| Outline | 907×1555.3 mm |
| Surface | Antiglare, Hard coating (2H), Antireflection |
| Contrast Ratio | 2000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 6 (Typ.)(G to G) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 64 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 8-bit), 61 pins |
| Input Voltage | 12.0V (Typ.) |
