| PartNumber | LM140LF1F01 |
| Brand | PANDA |
| Size | 14.0 |
| Application | Laptop Gaming |
| Resolution | 1920×1080 |
| Composition | LCM , Oxide TFT-LC |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | 9S6P WLED , 15K hours , With LED Driver |
| Interface | |
| Manufacturer | PANDA |
| Screen Size | 14.0 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 157PPI |
| Active Area(mm) | 309.312 × 173.988 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 300 (Typ.)(cd/m²) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 72% NTSC |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Refresh Rate | 120Hz |
| Model Name | LM140LF1F01 (NCP0050) |
| Screen Type | LCM , Oxide TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 315.81 × 197.57 × 2.4 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Work Mode | FFS, Normally Black, Transmissive |
| Response | 25 (Typ.)(Tr+Td) ms |
| Used for | Laptop Gaming |
| Touchscreen | Without |
| B140RW02 V0 | AUO | 14.0 | 1600×900 |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| B140XW02 V0 | AUO | 14.0 | 1366×768 |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLC1 | LG Display | 14.0 | 1366×768 |
| LTN140AT08-S03 | Samsung | 14.0 | 1366×768 |
| LTN140KT04-201 | Samsung | 14.0 | 1600×900 |
| N140BGE-L31 | Innolux | 14.0 | 1366×768 |
| N140HGE-EAA | Innolux | 14.0 | 1920×1080 |
