| PartNumber | LM230WF5-TLB1 |
| Brand | LG Display |
| Size | 23.0 |
| Application | DMPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LM230WF5-TLB1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 509.184×286.416 mm |
| Outline | 533.2×312×11.5 mm |
| Surface | Glare (Haze 0%), Hard coating (2H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC) |
| Response Time | 1.3/3.7 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| LM230WF1-TLA5 | LG Display | 23.0 | 1920×1080 |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLE1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLB1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| HT17E12-210 | HYDIS | 17.0 | 1280×1024 |
| LM185WH1-TLH1 | LG Display | 18.5 | 1366×768 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM190EX-L31 | Samsung | 19.0 | 1280×1024 |
| M201EW02 VG | AUO | 20.1 | 1680×1050 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| MT185WHM-N10 | BOE | 18.5 | 1366×768 |
