LM240WU5-SLA1


Brand
LG Display
Size
24.0
Application
DMPC
Resolution
1920×1200
Composition
LCM
Brightness
250
CR
1000:1
Colors
1.07B
Backlight
RGB LED
Interface
LVDS
In Stock
250
Specifications
PartNumber LM240WU5-SLA1
BrandLG Display
Size24.0
ApplicationDMPC
Resolution1920(RGB)×1200 , WUXGA
CompositionLCM
Brightness250 cd/m² (Typ.)
CR1000:1
Colors1.07B
BacklightRGB LED
InterfaceLVDS
Panel BrandLG.Philips LCD
Panel ModelLM240WU5-SLA1
Panel Type a-Si TFT-LCD , LCM
Panel Size24.0 inch
Display ModeS-IPS, Normally Black, Transmissive
Active Area518.4×324 mm
Outline546.4×352×48.9 mm
SurfaceAntiglare, Hard coating (3H)
Contrast Ratio1000:1 (Typ.)
Display Colors1.07B (10-bit), CIE1931110%
Response Time6/6 (Typ.)(Tr/Td); 6 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeRGB LEDEmbedded (LED Driver)
Signal InterfaceLVDS (2 ch, 10-bit), 51 pins
Input Voltage12.0V (Typ.)
