| PartNumber | LM270WR3-SPA1 |
| Brand | LG Display |
| Size | 27.0 |
| Application | Desktop Monitor |
| Resolution | 3840×2160 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | eDP |
| Model | LM270WR3-SPA1 |
| Diagonal Size | 27.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 3840(RGB)×2160 [UHD] 163PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 596.74(H)×335.66(V) mm |
| Outline Dim. | 621.8(H)×360.6(V) ×13.3(D) mm |
| Bezel Area | 602(H)×340.8(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 1.07B 100% sRGB |
| Light Source | WLED [18S4P] , 30K hours , W/O Driver |
| Weight | 3.11/3.27Kgs (Typ./Max.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector |
| Power Supply | 10.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
