| PartNumber | LM290WW2-SSB1 |
| Brand | LG Display |
| Size | 29.0 |
| Application | Desktop Monitor Industrial Medical Imaging |
| Resolution | 2560(RGB)×1080, CSHD, 96PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 17S4P |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Size | 29.0" |
| Display Area | 672.768(W)×283.824(H) mm |
| Outline Size | 693.6(W)×308.9(H) ×17.5(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 99% sRGB |
| Frequency | 60Hz |
| Panel Weight | 3.12/3.28Kgs (Typ./Max.) |
| Signal Interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Input Voltage | 10.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | LM290WW2-SSB1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 14 (Typ.)(G to G) |
| Lamp Type | 17S4P WLED , 30K hours , Without Driver |
| Touch Screen | Without |
