| PartNumber | LMG9980ZWCC-01 |
| Brand | KOE |
| Size | 12.1 |
| Application | IA |
| Resolution | 800(RGB)×600 , SVGA |
| Composition | LCM |
| Brightness | 70 cd/m² (Typ.) |
| CR | 30:1 |
| Colors | Color |
| Backlight | CCFL |
| Interface | Parallel Data |
| Panel Brand | HITACHI |
| Panel Model | LMG9980ZWCC-01 |
| Panel Type | CSTN-LCD , LCM |
| Panel Size | 12.1 inch |
| Display Mode | STN, Normally Black |
| Active Area | 246×184.5 mm |
| Outline | 275×202.5 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 30 : 1 (Typ.) |
| Display Colors | Color |
| Response Time | 170/130 (Typ.)(Tr/Td) |
| Viewing Angle | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| Frequency | 120Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel Data (8-bit), 41 pins |
| Input Voltage | 3.3/5.0V (Typ.)(VDD) |
