| PartNumber | LP123WQ1-SPA1 |
| Brand | LG Display |
| Size | 12.3 |
| Application | Laptop |
| Resolution | 2736×1824 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1400:1 |
| Colors | 16.7M |
| Backlight | WLED , 12K hours , No Driver |
| Interface | eDP |
| Manufacturer | LG Display |
| Model Name | LP123WQ1-SPA1 |
| Screen Size | 12.3 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 2736(RGB)×1824 267PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 259.78 × 173.19 (H×V) |
| Outline(mm) | 265.38 × 183.49 × 4.25 (H×V×D) |
| Bezel Area(mm) | 262.18 × 175.59 (H×V) |
| Treatment | Hard coating (3H) |
| Luminance | - |
| Contrast Ratio | 1400 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 27/46 (Max.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M |
| Outline Shape | Slim (PCBA Bent, T≤3.0mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , HBR2 (5.4G/lane) , Connector 60 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: 0 ~ 60 °C |
