| PartNumber | LP156WHB-TPL1 |
| Brand | LG Display |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 100PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | LG Display |
| Panel Size | 15.6" |
| Display Area | 344.232(W)×193.536(H) mm |
| Viewing Angle | - |
| Best View on | 6 o'clock |
| Display Colors | 262K |
| Frequency | 60Hz |
| Shape Style | - |
| Signal Interface | eDP (1 Lane) , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | LP156WHB-TPL1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 16 (Typ.)(Tr+Td) |
| Lamp Type | WLED , With LED Driver |
| Touch Screen | Without |
