| PartNumber | LPM013M461B |
| Brand | JDI |
| Size | 1.29 |
| Application | Wearable |
| Resolution | 260×260 |
| Composition | LCM , LTPS TFT-LCD |
| Brightness | |
| CR | 20:1 |
| Colors | 64 |
| Backlight | No B/L |
| Interface | |
| Manufacturer | JDI |
| Model Name | LPM013M461B |
| Screen Size | 1.29 inch |
| Screen Type | LCM , LTPS TFT-LCD |
| Pixel Number | 260(RGB)×260 201PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 32.76 × 32.76 (H×V) |
| Outline(mm) | 35.56 × 36.26 × 1.01 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Hard coating (2H) |
| Luminance | - |
| Contrast Ratio | 20:1 (Typ.) (RF) |
| Viewing Angle | 60/65/65/60 (Typ.)(CR≥2) |
| Response | 3/6 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | ECB, Normally Black, Reflective |
| Color Depth | 64 23% NTSC |
| Mass | 1.90g (Typ.) |
| Used for | Wearable |
| Refresh Rate | 30Hz |
| Touchscreen | Without |
| Voltage Supply | 3.2/4.5V (Typ.)(VDD1/VDD2) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| LPM010R030B | JDI | 0.99 | 180×180 |
| LPM012A154A | JDI | 1.2 | 218×218 |
| LPM013M091A | JDI | 1.34 | 320×300 |
