| PartNumber | LQ042T5DZ13A |
| Brand | Sharp |
| Size | 4.2 |
| Application | Industrial Automotiv |
| Resolution | 480×272 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | - |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 4.2 inch |
| Pixel Format | 480×272(RGB) [WQVGA] 131PPI |
| Active Area | 92.88(H)×52.632(V) mm |
| Bezel Area | 94.48(H)×54.27(V) mm |
| Luminance | 500 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 262K |
| Weight | 120g (Typ.) |
| Frame Rate | 50Hz |
| Model | LQ042T5DZ13A |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Horizontal Stripe |
| Outline Dim. | 102.5(H)×69(V) ×12.3(D) mm |
| Treatment | - |
| Contrast Ratio | - |
| Response Time | 15/5 (Typ.)(Tr/Td) |
| Operating Mode | ASV, Normally Black, Transmissive |
| Light Source | WLED , 10K hours , With LED Driver |
| Designed For | Industrial Automotive Display |
| Touch Panel | Without |
