| PartNumber | LQ043Y1DX01 |
| Brand | SHARP |
| Size | 4.3 |
| Application | MPH |
| Resolution | 480(RGB)×800 , WVGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 65K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ043Y1DX01 3 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 4.3 inch |
| Display Mode | ASV, Normally Black, Transmissive |
| Active Area | 56.16×93.6 mm |
| Outline | 62.46×105.9×2.3 mm |
| Surface | Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 65K , CIE193172% |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB, 45 pins |
| Input Voltage | 3.0/2.6V (Typ.)(VCI/VDDIO) |
