| PartNumber | LQ050W1LA0A |
| Brand | SHARP |
| Size | 5.0 |
| Application | UMPC |
| Resolution | 1024(RGB)×600 , WSVGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 450:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SHARP |
| Panel Model | LQ050W1LA0A |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 109.1×63.9 mm |
| Outline | 119×76.3×5.6 mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 450:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
