| PartNumber | LQ058T5DR03X |
| Brand | Sharp |
| Size | 5.8 |
| Application | Automotive Display |
| Resolution | 640×350 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | |
| Colors | 262K |
| Backlight | CCFL |
| Interface | |
| Model | LQ058T5DR03X |
| Diagonal Size | 5.8 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 640(RGB)×350 126PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 128.6(H)×70.35(V) mm |
| Outline Dim. | - |
| View Direction | - |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K |
| Light Source | CCFL [1 pcs] |
| Weight | - |
| Designed For | Automotive Display |
| Frame Rate | - |
| Touch Panel | Without |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
