| PartNumber | LQ097L1JY02Z |
| Brand | SHARP |
| Size | 9.7 |
| Application | PAD |
| Resolution | 2048(RGB)×1536 , QXGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SHARP |
| Panel Model | LQ097L1JY02Z |
| Panel Type | IGZO TFT-LCD , LCM |
| Panel Size | 9.7 inch |
| Display Mode | Normally Black, Transmissive |
| Active Area | 196.608×147.456 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 16.7M (8-bit) |
| Response Time | |
| Viewing Angle | |
| Frequency | 60Hz |
| Lamp Type | WLED |
| Signal Interface | eDP (4 Lanes) |
