| PartNumber | LQ123N1JX34 |
| Brand | Sharp |
| Size | 12.3 |
| Application | Laptop |
| Resolution | 1920(RGB)×1280, 188PPI |
| Composition | Oxide TFT-LCD, LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | 6S8P |
| Interface | eDP |
| Panel Brand | Sharp |
| Panel Model | LQ123N1JX34 (SHP1495) |
| Panel Size | 12.3" |
| Panel Type | Oxide TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 259.2(W)×172.8(H) mm |
| Bezel Opening | - |
| Outline Size | 265.26(W)×185.06(H) ×4.95(D) mm |
| Surface | - |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td); 22 (Typ.)(G to G) |
| Display Colors | 16.7M 100% NTSC |
| Lamp Type | 6S8P WLED , 15K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Slim (PCBA Bent, T≤3.0mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
