| PartNumber | LQ156Z1JW03 |
| Brand | SHARP |
| Size | 15.6 |
| Application | NBPC |
| Resolution | 3200(RGB)×1800 , Quad-HD+ |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SHARP |
| Panel Model | LQ156Z1JW03 |
| Panel Type | IGZO TFT-LCD , LCM |
| Panel Size | 15.6 inch |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Active Area | 345.6×194.4 mm |
| Outline | 358.12×207.56×2.9 mm |
| Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) |
| Surface | Antiglare (Haze 42%) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Voltage | 3.3V (Typ.) |
