| PartNumber | LQ173D1JW33 |
| Brand | Sharp |
| Size | 17.3 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 255PPI |
| Composition | Oxide TFT-LCD , LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | Sharp |
| Panel Size | 17.3" |
| Display Area | 382.12(W)×214.94(H) mm |
| Outline Size | 393.69(W)×252.1(H) ×4(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% Adobe RGB |
| Frequency | 60Hz |
| Shape Style | Flat (PCBA Flat, T3.4~4.0mm) |
| Signal Interface | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | LQ173D1JW33 (SHP145A) |
| Panel Type | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 45%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 12K hours , With LED Driver |
| Touch Screen | Without |
