| PartNumber | LQ800D3HA01 |
| Brand | Sharp |
| Size | 80 |
| Application | TV Sets |
| Resolution | 1920(RGB)×1080, FHD, 27PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | LVDS |
| Panel Brand | Sharp |
| Panel Model | LQ800D3HA01 |
| Panel Size | 80" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1771.2(W)×996.3(H) mm |
| Bezel Opening | - |
| Outline Size | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Display Mode | ASV, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 4 (Typ.)(G to G) |
| Glass Depth | - |
| Transmissivity | 6.51% (Typ.)(with Polarizer) |
| Display Colors | 1.07B 73% NTSC |
| Lamp Type | No B/L |
| Frequency | 120Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 16 source + 10 gate chips |
| Panel Weight | 7.80g (Typ.) |
| Signal Interface | LVDS (4 ch, 10-bit) , 92 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
