| PartNumber | LS024Q3UX12 |
| Brand | Sharp |
| Size | 2.4 |
| Application | Handheld & PDA |
| Resolution | 320×240 |
| Composition | CG-Silicon , LCM |
| Brightness | |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 2.4 inch |
| Pixel Format | 320(RGB)×240 [QVGA] 166PPI |
| Active Area | 48.96(H)×36.72(V) mm |
| Bezel Area | 49.86(H)×37.72(V) mm |
| Luminance | 450 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Support Color | 262K 72% NTSC |
| Weight | 9.50g (Typ.) |
| Frame Rate | 65Hz |
| Model | LS024Q3UX12 |
| Type | CG-Silicon , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 54.3(H)×46.8(V) mm |
| Treatment | - |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Response Time | 11/24 (Typ.)(Tr/Td) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Light Source | WLED [1S5P] , W/O Driver |
| Designed For | Handheld & PDA |
| Touch Panel | Without |
